Name: Desktop Usage TCP RFID Proximity POE Card Reader Writer With LCD Screen
Brand: White Smart Co., Limited
SKU: POE Card Reader
Availability: InStock

Home Products RFID Card Reader

Desktop Usage TCP RFID Proximity POE Card Reader Writer With LCD Screen

Product Details:

Place of Origin:	CHINA
Brand Name:	WS
Certification:	ROHS,REACH,POPS
Model Number:	POE Card Reader

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	Please contact us
Packaging Details:	1pcs/box,72pcs/carton
Delivery Time:	5-7days
Payment Terms:	TT,PAYPAL,WU
Supply Ability:	1,000pcs

Contact Now

Detailed Product Description

Printing:	Full Color Printing,Offset Printing	Name:	POE Card Reader
Application:	Access Control System,Smart Lock / Access Control / Animal ID And Waste Management	Keyword:	125khz Proximity Card,Hotel Card,pvc Blank White Card
Lead Time:	5-7 Working Days	Color:	Customized
Size:	125 * 85 * 27 Mm	Connection:	POE
Highlight:	POE Card Reader With LCD Screen , Desktop Usage POE Card Reader Writer , RFID Proximity Card Reader Writer

Desktop Usage TCP RFID Proximity POE Card Reader Writer With LCD Screen

Product Overview

The TCP RFID Proximity POE Card Reader Writer is a 13.56MHz desktop device featuring an LCD screen for clear display. This reader utilizes TCP/IP communication and can be configured via web interface or data commands. It supports reading and writing card data, with customizable LCD text display and a controllable buzzer.

Key Features

Supports ISO14443TYPEA series cards (read/write compatible)
TCP/IP interface with TCP communication protocol
45 × 25 dot matrix LCD screen for character display
Operating frequency: 13.56MHz
POE power supply (48V, 40mA)
Compact dimensions: 125 × 85 × 27 mm
Wide operating temperature range: -20℃ to 60℃
User-controllable buzzer for status indication

Technical Specifications

Supported Standards: ISO/IEC 14443 TypeA, TypeB (optional), ISO/IEC 15693 (optional)

Operating Systems: Windows98, XP7, Linux, Android

Frequency: 13.56MHz

Reading Distance: 0-80mm

Interface: TCP/IP

Dimensions: 125 × 85 × 27mm

Weight: 100g

Operating Temperature: -20℃ to 85℃

Operating Humidity: 5% to 95%

Power Supply: 5V stabilized power supply or POE; maximum working current: 400mA

Display: Two LED indicators (Red for mains, Green for status)

Additional Features: Built-in buzzer, supports reading 10 ID numbers (18 numbers optional)

Product Attributes

Attribute	Value
Printing	Full color printing, Offset Printing
Name	POE Card Reader
Application	Access Control System, Smart Lock, Animal ID, Waste Management
Keyword	125khz proximity card, Hotel card, PVC blank white card
Lead time	5-7 working days
Color	Customized
Size	125 × 85 × 27 mm
Connection	POE
