424 DNA NFC Epoxy Tags Printing Stickers For Phone Applications and Loyalty System

Product Details:

Place of Origin:	CHINA
Brand Name:	WS
Certification:	ROHS,REACH,POPS
Model Number:	Nfc Epoxy Tags

Payment & Shipping Terms:

Minimum Order Quantity:	200-500pcs
Price:	Please contact us
Packaging Details:	200pcs/bag,1000pcs/carton
Delivery Time:	5-7days
Payment Terms:	TT,PAYPAL,WU
Supply Ability:	1,000,000pcs per month

Contact Now Chat Now

Detailed Product Description

Chip:	NXP RFID NFC	Material:	80g Paper
Size:	Dia25mm	Protocol:	ISO14443A
Color:	White Or Printed	Packing:	1000pcs/roll Or Coustomized
Printing:	Full Color,UV,CMYK Costomized Printing,silkscreen,Digital Print	Material:	PET,PVC
Application:	Access Control,Mobile Payment,Glasses Retail/Warehouse Management	Thickness:	0.25+/-0.04mm,Customized
Reading Distance:	1~10cm,0-10m (related With The Reader)	Data Retention:	100,000 Programming Cycles
Highlight:	epoxy nfc tag sticker , phone nfc epoxy tag , phone nfc tag sticker

424 DNA NFC Epoxy Tags Printing Stickers For Phone Applications and Loyalty System

Product Specifications

Attribute	Value
Chip	NXP RFID NFC
Material	80g Paper
Size	dia25mm
Protocol	ISO14443A
Color	White or Printed
Packing	1000pcs/roll or customized
Printing	Full color, UV, CMYK customized printing, silkscreen, Digital Print
Material	PET, PVC
Application	Access control, Mobile payment, Glasses Retail/Warehouse Management
Thickness	0.25+/-0.04mm, Customized
Reading distance	1~10cm, 0-10m (related with the reader)
Data retention	100,000 Programming cycles

Product Description

The 424 DNA NFC Epoxy Tags feature a file-based memory structure of totally 416 bytes (compliant to NFC Forum Type 4 Tag and ISO/IEC 7816-4) with a Capability Container (CC) file to specify the NFC Forum tag operation, an NDEF file as well as an extra data file to protect sensitive content. Configurable access rights per file support different use cases of brand product manufacturers and service providers to meet specific security and operational requirements.

With 5 customer defined AES keys, 424 DNA enables advanced cryptographic functionalities - for the CMAC, optionally combined with encrypted data, for SUN, mutual authentication (secure host or reader authentication) and for secure access to the NDEF file and the extra data file.

424 DNA contains configurable features like optionally encrypting part of the NDEF file, and the fully encrypted communication mode to address privacy sensitive applications. The optional Random ID together with the encrypted chip UID/data that can be mirrored in the NDEF file, enables compliance with latest user data protection regulations.

Technical Details

Material: Paper, PVC, PET, Epoxy
Back material: Adhesive layer
Size: dia25mm, 35x35mm, 0.5-0.8mm thickness or customized size
Working frequency: 13.56MHz
Protocol: ISO 14443A
Printing: Full color printing, silk printing or white
Craft: Numbers, or customized
Data retention: 10 years
Write endurance: 100,000 cycles
Reading range: 2-5cm (related with the size of the antenna and power of reader)
Monthly output: 6,000,000pcs
Package: 400pcs in a box (6×9.3×12.5cm), 10 boxes in a carton, or customized
Lead time: 10-15 days for 5000pcs

Applications

Mobile Payment, Access Control Management, E-ticketing, Loyalty System, Marketing, etc.

NFC Marketing Tips

Using NFC Sticker to let clients enter your website easily
Using NFC Sticker to let customers enter your blog easily
Direct users to a "how to" video of your products with NFC Sticker
Direct users to receive coupons with NFC Sticker

Of course, you have more creative ways on applying NFC Stickers in various applications.

Key Benefits

Long read range due to high chip sensitivity
Ease of tag assembly due to high chip input capacitance
Consistent performance on different materials
Reliable operation in multi-reader environment
Prevention of unauthorized memory access due to read protection
Wide temperature range: -40°C up to +85°C

Company Capacity

We always focus on providing end users and distributors with better products, faster delivery and more favorable prices. We offer products including Inlay, Label, On-Metal Tag, Laundry Tag, Jewelry Tag, paper Ticket, Token, and Wristband etc. We also offer custom printed, roll, fanfold, sheet, digital and stock labels, inlay or tags. Our commitment is to meet your most demanding Tag needs.
