Water Resistant Washable RFID UHF Laundry Tags For Passive Textile Laundry
Washable RFID UHF Laundry Tags For Passive Textile Laundry And Washing
RFID clothing warehouse system uses advanced RFID tag technology with globally unique identifiers. These tags support long-range identification and feature strong environmental adaptability.
During production, RFID tags are encoded with important garment information and attached to corresponding clothing items. When combined with fixed and handheld readers, these tags enable automatic identification, data collection, and inventory management for efficient stock monitoring and asset tracking.
As the global economy develops, hotels, hospitals, and laundry services face increasing demands for handling thousands of work uniforms and linens. RFID laundry tags provide automated, intelligent solutions for textile management throughout washing, ironing, and storage processes.
For laundry operations, these tags help distinguish between different textile types and cleaning cycles while solving challenges in quick cleaning, storage organization, and delivery management. RFID technology ensures accurate linen counts and improves overall laundry efficiency.
Advantages of UHF Laundry Tags
- Track garments throughout their complete lifecycle from arrival to dispatch
- Enable simultaneous reading of multiple tags
- Robust, waterproof construction withstands various environmental conditions including heat, humidity, pressure, water, and chemicals
RFID UHF Laundry Tags Specifications
| RFID Standard |
ISO/IEC 18000-6 TypeC (EPC Gen2) |
| Size & Weight |
88(W)x4.0(D)x4.0(H)mm, 1.85 g |
| Chip Type |
Alien Higgs-3, MR6, U CODE7 |
| EPC Memory |
96 bits to 480 bits |
| User Memory |
512 bits |
| Reading Range |
902-928 MHz | 3.0-7.0m
866-868 MHz | 3.0-6.0m |
| Tagging |
Sewing, Insert |
| Estimated Lifetime |
225 washing cycles or 3 years |
Environmental Resistance
| Washing Method |
Laundry, Dry cleaning |
| Water Extraction Pressure |
60 bar |
| Water Resistance |
Water resistant |
| Chemical Resistance |
Detergent, Softener, Bleach (Oxygen/Chlorine), Alkali |
| Heat Sterilization |
125ºC for 15-20 minutes - 150 cycles |
| Heat Resistance |
Drying: 85°C (Up to 60min.) 120°C (Up to 30 min.)
Ironing: 230°C (Up to 60 sec. with press cloth) |
| Humidity/Temperature |
Operating: -20 to 50°C, 10 to 95%RH
Storage: -40 to 55°C, 8 to 95%RH |
Textile Material Specifications
| MAXIMUM TEMPERATURE EXPOSURE: |
220℃ (392℉) | 30Seconds | 2.5 bars(36,28PSI) |
| WASHING: |
100℃ (194℉) | 60minutes 120Bar |
| PRE-DRYING IN TUMBLER: |
160℃ (320℉) | 30minutes |
| TUNNEL FINISHER: |
185℃ (365℉) | 30minutes |
| STERILIZATION PROCESS: |
134℃ (273℉) | 20minutes |
| WATER EXTRACTOR PRESS: |
120bars |
| WARRANTY: |
250 cycles or 3 years (New Encapsulation) |
Three Ways of Using RFID Laundry Tag
Frequently Asked Questions
Q1: I'm interested in your products, but now I'm out of China; could you offer you labels to my country?
A1: Sure! We've got full exportation experience, and no matter where you are, we may arrange the delivery for you, either by sea, by air or by express, depending on your need.
Q2: How can I get the samples?
A2: We can provide you free sample for our existing products, the lead time is around 1-2 days. You need to pay for the sample delivery cost. If you need the samples according to your design, the sample cost has to be charged from you. The lead time is around 5 days.
Q3: Is it possible to custom the labels with my own design?
A3: Yes, and you just need send us your drawings or artworks, then you can get what you want.
Q4: What is your MOQ?
A4: For label stickers, the MOQ is 1000 pcs for each design. For thermal transfer ribbon, the MOQ is 10 rolls for each type and size.
Q5: Do you provide OEM service?
A5: Yes. Actually, we're already OEM for some brand, and also do the specific packing for them.
Q6: What is your manufacture lead time for our order?
A6: Our normal lead time is 15-20 days. If you have urgent request, please just let us know. We will try our best to shorten the lead time to meet your requirements.
Q7: How can I release the payment to you?
A7: We can receive your payment by Paypal, Western union or Bank Account.
