Name: SRI512 Print Plastic Loyalty Cards , ISO 14443 B Rfid 13.56 Mhz Card
Brand: White Smart Co., Limited
SKU: SRI 512
Availability: InStock

Home Products RFID Smart Card

SRI512 Print Plastic Loyalty Cards , ISO 14443 B Rfid 13.56 Mhz Card

Product Details:

Place of Origin:	CHINA
Brand Name:	WS
Certification:	ROHS,REACH,POPS
Model Number:	SRI 512

Payment & Shipping Terms:

Minimum Order Quantity:	200-500pcs
Price:	Please contact us
Packaging Details:	200pcs/box,2000pcs/carton,3000pcs/carton
Delivery Time:	5-7days
Payment Terms:	TT,PAYPAL,WU
Supply Ability:	1,000,000pcs per month

Contact Now

Detailed Product Description

Printing Type:	Screen Printing/digital Printing,custom	Material:	PVC/PET/PETG
Individualization:	Custom, Embossing Or Print Name, Number,date Etc	Print:	Blank/print
Size:	CR80, 85.5*54mm
Highlight:	iso 14443 b rfid 13.56 mhz card , plastic rfid 13.56 mhz card , plastic 13.56 mhz smart card

SRI512 Print Plastic Loyalty Cards, ISO 14443 B RFID 13.56 MHz Card

Product Specifications

Printing Type	Screen Printing/digital Printing, custom
Material	PVC/PET/PETG
Individualization	Custom, embossing or print name, number, date etc
Print	Blank/print
Size	CR80, 85.5*54mm

Technical Details

ISO 14443-2 Type B air interface compliant
ISO 14443-3 Type B frame format compliant
13.56 MHz carrier frequency
847 kHz subcarrier frequency
106 Kbit/second data transfer
8 bit Chip_ID based anticollision system
2 Count-down binary counters with automated antitearing protection
64-bit Unique Identifier
512-bit EEPROM with Write Protect feature
READ BLOCK and WRITE BLOCK (32 bits)
Internal tuning capacitor
1 million ERASE/WRITE cycles

Product Parameters

Material: PVC/ABS/PET/Paper

Size: ISO CR80 standard (85.5mm x 54mm) or customized

Thickness: 0.8-0.84mm

Minimum QTY: 500pcs.

Chips Available: S50/S70/Ultralight/1K/2K/4K/8K/Fudan chip/2/203 etc

Operating Frequency: 13.56Mhz

Standard: ISO14443A/ISO14443B/ISO 15693 RFID card

Read Times: >100,000

Surface: glossy, matte, frosting

Available Customizations

4 color off-set printing, magnetic stripe, embossing number, signature panel, photo, barcode, thermal printing, gold/silver color scratch-off, series number punch, hole punched, UV printing, etc.

Personalization Options

Offset Printing with CMYK or Pantone colors, Silk-screen printing with metallic/silver effect, Magnetic Stripe HiCo2750/HiCo4000/LoCo300, Serial Number or UID number printing, Signature Panel, Barcode printing, Photo personalization, Chip encoding, Hologram, UV printing, Laser Logo, Laser Serial Number

Applications

Public transportation Event ticketing Loyalty system NFC application

Packaging Details

For standard card (85.5*54*0.86mm):

Inner box: 215×90×55mm (200pcs/box)

Carton: 485×230×305mm (25boxes/CTN)

Standard size card weight: 1,000pcs ≈ 6kg
