Name: Contact Loyalty Custom Plastic Membership Cards With RFID Plus® X 4K 7 Bytes
Brand: White Smart Co., Limited
SKU: RFID Plus® (X) 4K 7bytes Card
Availability: InStock

Home Products RFID Smart Card

Contact Loyalty Custom Plastic Membership Cards With RFID Plus® X 4K 7 Bytes

Product Details:

Place of Origin:	CHINA
Brand Name:	WS
Certification:	ROHS,REACH,POPS
Model Number:	RFID Plus® (X) 4K 7bytes Card

Payment & Shipping Terms:

Minimum Order Quantity:	200-500pcs
Price:	Please contact us
Packaging Details:	200pcs/box,2000pcs/carton,3000pcs/carton
Delivery Time:	5-7days
Payment Terms:	TT,PAYPAL,WU
Supply Ability:	1,000,000pcs per month

Contact Now Chat Now

Detailed Product Description

Product Name:	Plastic Loyalty Cards	Printing Type:	4-color Offset Printing , Silk-screen Printing ,Thermal Printing , Digital Printing , Magnetic Stripe , Barcode
Material:	PVC , Plastic	Individualization:	Custom, Embossing Or Print Name, Number,date Etc
Application:	Club,advertisement,traffic,supermarket,parking,bank, Government	Available Craft:	Signature Panel , Series Number Printing, Hole Punch
Highlight:	plastic rfid smart card , plastic smart rfid card , pvc rfid smart card

Contact Loyalty Custom Plastic Membership Cards With RFID Plus® X 4K 7 Bytes

Product Specifications

Attribute	Value
Product name	Plastic Loyalty Cards
Printing Type	4-color offset printing, Silk-screen printing, Thermal printing, Digital printing, Magnetic stripe, Barcode
Material	PVC, plastic
Individualization	Custom, embossing or print name, number, date etc
Application	Club, advertisement, traffic, supermarket, parking, bank, government
Available Craft	Signature panel, Series number printing, Hole punch

Product Description

Contact custom membership Plastic Loyalty Cards with RFID Plus® x 4K 7 bytes

Key Features

2 or 4 Kbytes EEPROM
Simple fixed memory structure compatible with RFID Classic (RFID Mini, RFID Classic®1k, RFID Classic®4k)
Memory structure as in RFID Classic®4k (sectors, blocks)
Unique serial number (4 or 7 byte)
Multi-sector authentication
Multi-block read
Anti-tear function for writing AES keys
Keys can be stored as RFID Classic keys (2 x 48 bit per sector) or AES keys (2 x 128 bit per sector)
Access conditions freely configurable
Number of single write operations: 200,000

RFID Smart Card RFID Plus® (X) 4K 7bytes Card brings increased security to end-user solution providers together with a seamless upgrade of existing infrastructure and services with low cost procedures. This new RFID product is supported by card and reader manufacturers and solution developers, and is the only RFID Classic-compatible mainstream smart card IC featuring pre-issuance of cards prior to infrastructure changes.

Chip type: RFID Plus® (X) 4K 7bytes
Size: 85.5*54 mm or customer request
Thickness: 0.86mm
Materials: PVC, PET...
Working Frequency: 13.56MHz
Function: Write/Read

Technical Specifications

ISO standard contact and Contactless Smart Card

1. Physical
Dimension:	ISO CR80 Standard: 85.5mm*54mm or customized
Thickness:	0.84mm or customized
Weight:	6g +/-0.5g
Standard color:	Color or blank
Surface:	Glossy / Matte / Frosted
2. Material	PVC, PET, PETG, ABS, PAPER
3. Chips available	Contact Smart Card Chips SLE 4442 / SLE 4428 ISSI 4442 / 4428 / 1604 / 24C02 / 24C04 / 24C16 / 24C64 FM 4442 / 4428 / 1604 / 24C02 / 24C04 / 24C16 / 24C64 LF 125KHz Chips (ISO 11784/5) EM 4200/4205/4305/4450/4469 ATA5567/ ATA5577/TK4100 1, 2, S256, S2048, UR064 Memory Size: 8byte / 32byte /64byte /128byte /256byte HF 13.56MHz Chips (ISO 14443A/B,15693) Mifar S20/50/70,Mifar Ultralight/C Mifar EV1 2K/4K/8K, I CODE SLI S/I CODE 2 Mifar Plus S 2K/4K,Mifar Plus X 2K/4K ISSI 4439/4469 FUDAN FM11RM08/1RM32,FM1302N/1302T,FM11RM005U TEXAS INSTRUMENT TI 256/2048 HUADA S70,TK S50,and so on Memory Size: 64byte / 128byte /192byte /256byte /320byte/1/2/4/8Kbyte UHF 915MHz Chips (ISO 18000 6B/6C) U CODE G2 XM/L , U CODE HSL Alien Higgs-3 Impinj MONZA 3/4D/4E/4QT/5 Memory Size: 32bit / 96bit /128bit /512bit /2048bit
4. Write Cycle	100,000
5. Reading Distance	0-10m (According to the chip and the design of the antenna of the reader)
6. Working Temp	-20~+70°C
7. Available Craft	4-color offset printing, Silk-screen printing, Thermal printing, Digital printing, Magnetic stripe, Barcode Hot-stamping gold/silver color, Signature panel, Series number printing, Hole punch, UV printing etc.
8. Application	Commercial electronic consumption / Medical care/ Attendance management / Banking business Door access control / Transportation / Electrc ticket / Membership management / Car parking / Express way toll gate / Metro card / Anti-theft / Identification
9. Payment	L/C,T/T or Western Union. 50% deposit of the total payment before bulk production.
10. Lead Time	5~15 workdays after the receipt of 50% deposit of the total payment, according to order quantity
11. Weight	1,000pcs:7Kg
