Dia 25mm RFID Chip Inlay 13.56MHZ RFID Dry Inlay 1cm-3cm Reading Range

D25mm RFID Dry inlay / wet inlay ISO 14443A RFID Classic(R) 1K

• Inlays with ink marks are defective, do not use
• RFID Inlays or labels are sensitive product, do not bend or stretch
• Static-free bag will be used for packing; always keep environmental static charge to a minimum
• All products should be tested by the customer/user thoroughly to ensure the product meets particular requirements

• Contactless transmission of data and supply energy (no battery needed)
• Operating distance: Up to 100mm (depending on antenna geometry)
• Operating frequency: 13.56 MHz
• Data transfer: 106 kbit/s
• Data integrity: 16 Bit CRC, parity, bit coding, bit counting
• Anticollision
• Typical ticketing transaction: < 100 ms (including backup management)
• 1 Kbyte memory organized in 16 sectors with 4 blocks of 16 bytes each
• User definable access conditions for each memory block
• Data retention of 10 years
• Write endurance 100,000 cycles

We specialize in providing high-quality RFID products including Inlays, Labels, On-Metal Tags, Laundry Tags, Jewelry Tags, Paper Tickets, Tokens, and Wristbands. Our services include custom printing and various packaging options (roll, fanfold, sheet, digital) to meet your specific tag requirements.

• Quantity per roll: 12,800±300pcs/roll; 1roll/carton
• Two lines of 25mm interleaf to protect IC and antenna
• Packaged in static-free bags
• Must be kept away from water, collision and static
