Name: PET Material Dry HF RFID Inlay 13.56MHz RFID Label Tag 40x40mm 22x35mm
Brand: White Smart Co., Limited
Availability: InStock

Home Products HF RFID Inlay

PET Material Dry HF RFID Inlay 13.56MHz RFID Label Tag 40x40mm 22x35mm

Product Details:

Place of Origin:	CHINA
Brand Name:	WS
Certification:	ROHS,REACH,POPS

Payment & Shipping Terms:

Minimum Order Quantity:	200-500pcs
Price:	Please contact us
Packaging Details:	2,000pcs/roll,5,000pcs/roll
Delivery Time:	5-7days
Supply Ability:	1,000,000pcs per month

Contact Now

Detailed Product Description

Material:	PET	RFID:	NFC
Frequency:	13.56MHZ	Reading Range:	1-3CM
Antenna:	Etched Antenna
Highlight:	40x40mm HF RFID Inlay , 13.56MHz Dry RFID Inlay , PET Material HF RFID Inlay

PET Material Dry HF RFID Inlay 13.56MHz RFID Label Tag 40x40mm 22x35mm

Product Specifications

Material	PET
RFID Technology	NFC
Frequency	13.56MHz
Reading Range	1-3CM
Antenna Type	Etched antenna

Product Details

RFID Classic(R) 1K label tag RFID Dry inlay/wet inlay

Frequency	HF 13.56MHz
Inlay Size	Dia 21mm
Wet Inlay Size	Dia 25mm
Memory Capacity	144/504/888bytes
Antenna	Aluminium etching antenna
Bonding	Flip chip
Unwinding	Chip side up
Thickness	0.07mm
Reading Distance	1.5~3cm (depends on reader applied)
Operation Temperature	-20°C~+65°C
Storage Temperature	-25°C~+65°C
Data Storage	≥10 years
Packing	10,000pcs/roll each roll in an inner case, 4 rolls per master carton

Handling Instructions

Inlays with ink marks are defective and should not be used
RFID Inlays or labels are sensitive products - avoid bending or stretching
Static-free bags used for packing; maintain minimal environmental static charge
Products should be thoroughly tested by customers to ensure suitability

Product Images

Note: Product images are for reference only. All intellectual property rights related to trademarks belong to their respective owners. Specifications subject to change without notice.
