Name: PVC / PET Material RFID Key Cards Access Control Hotel Keycards 320bytes Memory
Brand: White Smart Co., Limited
Availability: InStock

Home Products RFID Key Cards

PVC / PET Material RFID Key Cards Access Control Hotel Keycards 320bytes Memory

Product Details:

Place of Origin:	CHINA
Brand Name:	WS
Certification:	ROHS,REACH,POPS

Payment & Shipping Terms:

Minimum Order Quantity:	200-500pcs
Price:	Please contact us
Packaging Details:	200pcs/box,2000pcs/carton,3000pcs/carton
Delivery Time:	5-7days
Payment Terms:	TT,PAYPAL,WU
Supply Ability:	1,000,000pcs per month

Contact Now

Detailed Product Description

Product Name:	Hotel Key Card	Antenna Size:	Customized
Reading Distance:	0---10CM	Write Endurance:	100, 000 Cycles
Frequency:	13.56MHZ	Material:	PVC/PET
Chip:	RFID Mini S20	Memory:	320bytes
Thickness:	0.8-0.9mm
Highlight:	PET Material RFID Key Cards , Access Control PVC Hotel Keycards , 320bytes Memory Blank Key Cards

PVC/PET Material RFID Key Cards with 320bytes Memory

Product Specifications

Attribute	Value
Product Name	Hotel Key Card
Antenna Size	Customized
Reading Distance	0-10CM
Write Endurance	100,000 cycles
Frequency	13.56MHZ
Material	PVC/PET
Chip	RFID mini S20
Memory	320bytes
Thickness	0.8-0.9mm

Product Description

Our PVC/PET RFID cards with RFID mini S20 chip provide affordable access control solutions for hotels, gyms, and other businesses. Designed to operate with key card door lock systems, these cards can be customized to promote your brand, service offerings, and special events.

We offer versatile solutions including key tags and employee security badges. Choose from magnetic stripe or ISO 14333A compliant RFID key cards. Our products work with all major key card door lock brands:

Onity
Kaba
ILCO
Saflok
Tesa
Sargent
Cisa
TimeLox
Miwa
Inhova

Technical Details

Chip	RFID mini S20
Material	PVC/PET
Memory	320bytes
Antenna	Aluminium etching antenna/copper antenna
Thickness	0.8-0.9mm
Reading Distance	0-10cm (depends on reader applied)
Operation Temp.	-20°C~+65°C
Storage Temp.	-25°C~+65°C
Data Storage	≥10 years

RFID mini S20 Features

RF Interface (ISO/IEC 14443 A)

Contactless transmission of data and supply energy (no battery needed)
Operating distance: Up to 100mm (depending on antenna geometry)
Operating frequency: 13.56 MHz
Data transfer: 106 kbit/s
Data integrity: 16 Bit CRC, parity, bit coding, bit counting
Anticollision
Typical ticketing transaction: < 50 ms (including backup management)

EEPROM

320 Byte, organized in 5 sectors with 4 blocks of 16 bytes each
User definable access conditions for each memory block
Data retention of 10 years
Write endurance 100,000 cycles

Security

Mutual three pass authentication (ISO/IEC DIS 9798-2)
Individual set of two keys per sector to support multi-application with key hierarchy
Unique serial number for each device

Frequently Asked Questions

Q1: I'm interested in your products, but now I'm out of China; could you offer you labels to my country?

A1: Sure! We've got full exportation experience, and no matter where you are, we may arrange the delivery for you, either by sea, by air or by express, depending on your need.

Q2: How can I get the samples?

A2: We can provide you free sample for our existing products, the lead time is around 1-2 days. You need to pay for the sample delivery cost. If you need the samples according to your design, the sample cost has to be charged from you. The lead time is around 5 days.

Q3: Is it possible to custom the labels with my own design?

A3: Yes, and you just need send us your drawings or artworks, then you can get what you want.

Q4: What is your MOQ?

A4: For label stickers, the MOQ is 1000 pcs for each design. For thermal transfer ribbon, the MOQ is 10 rolls for each type and size.

Q5: Do you provide OEM service?

A5: Yes. Actually, we're already OEM for some brand, and also do the specific packing for them.

Q6: What is your manufacture lead time for our order?

A6: Our normal lead time is 15-20 days. If you have urgent request, please just let us know. We will try our best to shorten the lead time to meet your requirements.

Q7: How can I release the payment to you?

A7: We can receive your payment by Paypal, Western union or Bank Account.
