Product Details:
|
| Printing Type: | Offset/Screen Printing/digital Printing,custom | Material: | PVC/PET/PETG |
|---|---|---|---|
| Individualization: | Custom, Embossing Or Print Name, Number,date Etc | Print: | Blank/print |
| Size: | CR80, 85.5*54mm | ||
| Highlight: | iso 14443 b rfid 13.56 mhz card,plastic rfid 13.56 mhz card,plastic 13.56 mhz smart card |
||
SRI512 RFID Print Plastic Loyalty Cards , ISO 14443 B 13.56MHZ Card
ST Smart Card Specifications
■ ISO 14443-2 Type B air interface compliant
■ ISO 14443-3 Type B frame format compliant
■ 13.56 MHz carrier frequency
■ 847 kHz subcarrier frequency
■ 106 Kbit/second data transfer
■ 8 bit Chip_ID based anticollision system
■ 2 Count-down binary counters with automated
antitearing protection
■ 64-bit Unique Identifier
■ 512-bit EEPROM with Write Protect feature
■ READ BLOCK and WRITE BLOCK (32 bits)
■ Internal tuning capacitor
■ 1million ERASE/WRITE cycles
■ 40-year data retention
■ Self-timed programming cycle
■ 5 ms typical programming time
■ Packages
– ECOPACK® (RoHS compliant)
RFID Smart Card Parameter
|
Material: |
PVC/ABS/PET/Paper |
|
Size: |
ISO CR80 standard(85.5mm x 54mm) or customized |
|
Thickness: |
0.8-0.84mm |
|
Minimum QTY: |
500pcs. |
|
Chips Available: |
S50/S70/Ultralight / 1K/2K/4K/8K/Fudan chip/ 2/203 etc |
|
Operating Frequency: |
13.56Mhz |
|
Standard: |
ISO14443A/ ISO14443B/ISO 15693 RFID card |
|
Read Times: |
>100 000 |
|
Available Crafts: |
4 color off-set printing, magnetic stripe, embossing number, signature panel, photo, barcode, thermal printing, gold/shiver color scratch-off, series number punch, hole punched, UV printing, etc. |
|
Surface: |
glossy, matte, frosting |
|
Price Items: |
We accept FOB/CNF/CIF price. |
|
Payment Term: |
Paid by T/T or Western Union |
|
Lead Time: |
5~7days after checking the payment |
|
Delivery Way: |
By express delivery, by sea or by air |
|
Package Details |
For standard card(85.5*54*0.86mm): |
|
Sample Supply: |
Free samples are available upon request |
|
Certificate: |
ISO 9001-2008 |
|
Disclaimer: |
The showing picture is only for your reference of our product. |
Smart Card Personalization Support:
Offset Printing with CMYK or Pantone colors/ Silk-screen printing with metallic, sliver effect/ Magnetic Stripe HiCo2750, HiCo4000 or LoCo300/ Serial Number or UID number printing/ Signature Panel/ Barcode printing/ Photo personalization/ Chip encoding/ Hologram/ UV printing / Laser Logo / Laser Serial Number
Application:
Public transportation/ even ticketing / Loyalty system / NFC application
