Product Details:
|
| Name: | Plastic Smart Card | Size: | ISO CR80 Standard(85.5mm X 54mm) Or Customized |
|---|---|---|---|
| Material: | PVC/ABS/PET/Paper | Frequency: | 13.56Mhz |
| Thickness: | 0.8-0.84mm | Surface: | Glossy, Matte, Frosting |
| Highlight: | 0.8mm Thick 13.56MHZ RFID Card,ISO 14443 B Standard Plastic RFID Card,0.84mm Thickness Smart RFID Card |
||
SRI512 white smart card ISO 14443 B 13.56MHZ smart card
ST Smart Card Specifications
■ ISO 14443-2 Type B air interface compliant
■ ISO 14443-3 Type B frame format compliant
■ 13.56 MHz carrier frequency
■ 847 kHz subcarrier frequency
■ 106 Kbit/second data transfer
■ 8 bit Chip_ID based anticollision system
■ 2 Count-down binary counters with automated
antitearing protection
■ 64-bit Unique Identifier
■ 512-bit EEPROM with Write Protect feature
■ READ BLOCK and WRITE BLOCK (32 bits)
■ Internal tuning capacitor
■ 1million ERASE/WRITE cycles
■ 40-year data retention
■ Self-timed programming cycle
■ 5 ms typical programming time
■ Packages
– ECOPACK® (RoHS compliant)
RFID Smart Card Parameter
Material: | PVC/ABS/PET/Paper |
Size: | ISO CR80 standard(85.5mm x 54mm) or customized |
Thickness: | 0.8-0.84mm |
Minimum QTY: | 500pcs. |
Chips Available: | S50/S70/Ultralight / 1K/2K/4K/8K/Fudan chip/ 2/203 etc |
Operating Frequency: | 13.56Mhz |
Standard: | ISO14443A/ ISO14443B/ISO 15693 RFID card |
Read Times: | >100 000 |
Available Crafts: | 4 color off-set printing, magnetic stripe, embossing number, signature panel, photo, barcode, thermal printing, gold/shiver color scratch-off, series number punch, hole punched, UV printing, etc. |
Surface: | glossy, matte, frosting |
Price Items: | We accept FOB/CNF/CIF price. |
Payment Term: | Paid by T/T or Western Union |
Lead Time: | 5~7days after checking the payment |
Delivery Way: | By express delivery, by sea or by air |
Package Details | For standard card(85.5*54*0.86mm): |
Sample Supply: | Free samples are available upon request |
Certificate: | ISO 9001-2008 |
Disclaimer: | The showing picture is only for your reference of our product. |
Smart Card Personalization Support:
Offset Printing with CMYK or Pantone colors/ Silk-screen printing with metallic, sliver effect/ Magnetic Stripe HiCo2750, HiCo4000 or LoCo300/ Serial Number or UID number printing/ Signature Panel/ Barcode printing/ Photo personalization/ Chip encoding/ Hologram/ UV printing / Laser Logo / Laser Serial Number
Application:
Public transportation/ even ticketing / Loyalty system / NFC application
Competitive Advae:
Our service:
1. We will reply you as soon as possible after receiving your enquiry.
2. We can offer both OEM and ODM service according to customers' request.
3. If novelties exist in any non-human-made problems, please contact us at your first
time and we will offer you a satisfactory solution according to actual situation.
4. The lead time of samples would be 1-7 days.
